The chisel is wearing part of a hydraulic hammer breaker. The tip of chisel would be worn during the working process, it is mainly used in ore, roadbed, concrete, ship, slag, etc working site. It is necessary to pay attention to the daily maintenance, such as the inner and outer bushes replacement and grease supplement. Otherwise, the chisel would be broken. So the correct selection and use of chisel is the key to hydraulic hammer breaker loss reduction.

Selection Guide of chisel

  1. Flat / Wedge chisel: suitable for soft and neutral layer rocks excavation, concrete breaking, and excavation of ditches.
  2. Moil point chisel: suitable for hard stone, extra hard rock, and reinforced concrete excavation and broken.
  3. Conical chisel: mainly used in breaking tough rocks, such as granite, and quartzite in quarry, also used for breaking heavy and thickened concrete.
  4. Blunt chisel: mainly used in breaking medium-hard rocks or small cracked stones to make them smaller

Hydraulic Breaker Chisel

Posted on
Hydraulic Breaker Chisel Main Advantages of JIANGTU Chisel: Material: 42 CrMo CNC machine to make it more accuracy Full controlled Capacity for whole process of heat treatment All QC data was…

Replacement of chisel

Remove the stop pin and the 330mm long chisel pin at first. When next installing, please insert the chisel into the pin when the chisel is put in the level position.

When re-installing, please proceed in the reverse sequence of disassembly. First, check whether all parts are worn or cracked. It should be polished and repaired If the chisel is deformed. The whole chisel should be coated with lubricate oil, then install the chisel. If the chisel pin is seriously deformed, it is difficult in replacing the chisel. So pay attention to checking the chisel and chisel pin every 100-150 hours.

Operating direction of the chisel

When operating, the direction of the chisel and the excavator’s arm should be the same, and the chisel should be vertical to the rock surface. If the chisel is not vertical to the rock surface, the chisel may slip during work. When breaking, please adjust the chisel direction firstly, and then break the rock from the suitable hitting point of the rock under the stability condition.

Instructions for chisel operation:

  1. A suitable downward force can improve the efficiency of the hydraulic hammer breaker.
  2. The position of the hammer breaker adjustment – when the hammer breaker cannot break the rock, it should be moved to a new hitting point.
  3. The breaking operation shall not be operated continuously at the same position. The the temperature of chisel would rise when breaking at the same position for a long time. The chisel hardness would be reduced to damage the tip of chisel, thereby the operation efficiency cut down.
  4. Do not use the chisel as a lever to pry rocks. ​​
  5. Please put down the excavator arm to a safe state when stopping operation. Don’t leave the excavator when the engine is started. Please ensure all brake and locking devices ineffective state.

JIANGTU Attachments, as a breaker manufacturer for 12 years. We could provide various types of hydraulic hammer breakers and the chisel selection recommendation and installation instructions for you. If you have any questions, please feel free to contact us.
